Пример:
Поводите мышкой по изображению ниже
- Для примера использовалась фотография "gymlines.jpg"
- Если нужно наложить текст или другие элементы на данный фон, можно использовать варианты из предыдущих тем в разделе "Фоны и паттерны"
- Изменив фон и цвет линий, например на черный, эффект подойдет не только для детского или спортивного сайта.
HTML:
|
1 |
<canvas id="mouse-line"></canvas> |
CSS:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 |
#mouse-line { user-select: none; width: 100%; height: 500px; background-color: #000; background-image: url(/demo/i/gymlines.jpg); background-size: cover; background-position: 50% 50%; margin: 20px 0; } @media (max-width: 768px) { #mouse-line { height: 300px; } } |
JS:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 |
// Imagination by @neave window.requestAnimationFrame = window.requestAnimationFrame || window.webkitRequestAnimationFrame || window.mozRequestAnimationFrame || window.msRequestAnimationFrame || function(callback) { setTimeout(callback, 1000 / 60); }; var get = document.querySelector.bind(document), on = document.addEventListener.bind(document), container = document.querySelector('.mouse-line-container'), context, canvas, mouseX, mouseY, px, py, points = [], size = 0, red = 0, green = 255, blue = 255, spread, SPEED_X = 0.15, SPEED_Y = 0.15, MAX_LENGTH = 120, RED_STEP = 0.02, GREEN_STEP = 0.015, BLUE_STEP = 0.025; function Point(x, y, dx, dy, size, color) { this.x = x; this.y = y; this.dx = dx; this.dy = dy; this.size = size; this.color = color; } Point.prototype.spread = function() { this.x += this.dx; this.y += this.dy; }; function drawLines() { var p0, p1, p2, total = points.length; for (var i = total - 1; i > 1; i--) { p0 = points[i]; p1 = points[i - 1]; p2 = points[i - 2]; context.beginPath(); context.strokeStyle = p0.color; context.lineWidth = p0.size; context.globalAlpha = i / total; context.moveTo((p1.x + p0.x) / 2, (p1.y + p0.y) / 2); context.quadraticCurveTo(p1.x, p1.y, (p1.x + p2.x) / 2, (p1.y + p2.y) / 2); context.stroke(); p0.spread(); } points[0].spread(); points[total - 1].spread(); } function draw() { // Line movement var dx = (mouseX - px) * SPEED_X, dy = (mouseY - py) * SPEED_Y; // Limit the amount of movement if (dx < -spread) { dx = -spread; } else if (dx > spread) { dx = spread; } if (dy < -spread) { dy = -spread; } else if (dy > spread) { dy = spread; } // Store the mouse position px = mouseX; py = mouseY; // Create a new point on the line points.push(new Point( px, py, dx, dy, Math.abs(Math.sin(size += 0.125) * 10) + 1, 'rgb(' + (Math.floor(Math.sin(red += RED_STEP) * 128 + 128)) + ',' + (Math.floor(Math.sin(green += GREEN_STEP) * 128 + 128)) + ',' + (Math.floor(Math.sin(blue += BLUE_STEP) * 128 + 128)) + ')' )); // Remove the last point from the list if we've reached the maximum length if (points.length > MAX_LENGTH) points.shift(); // Fade out //context.globalCompositeOperation = 'source-over'; //context.globalAlpha = 1; //context.fillStyle = 'rgba(0, 0, 0, 0.05)'; //context.fillRect(0, 0, canvas.width, canvas.height); context.clearRect(0, 0, canvas.width, canvas.height); // Draw the lines context.globalCompositeOperation = 'lighter'; drawLines(); drawLines(); drawLines(); } function update() { requestAnimationFrame(update); draw(); } function resize() { canvas.width = canvas.offsetWidth; canvas.height = canvas.offsetHeight; } function init() { canvas = get('#mouse-line'); context = canvas.getContext('2d'); canvas.onmousemove = function(event) { mouseX = event.clientX - canvas.getBoundingClientRect().left; mouseY = event.clientY - canvas.getBoundingClientRect().top; }; document.onmouseenter = function(event) { mouseX = event.clientX - canvas.getBoundingClientRect().left; mouseY = event.clientY - canvas.getBoundingClientRect().top; for (var i = points.length; i--; ) { points[i].x = mouseX; points[i].y = mouseY; } }; canvas.ontouchmove = function(event) { mouseX = event.targetTouches[0].clientX - canvas.getBoundingClientRect().left; mouseY = event.targetTouches[0].clientY - canvas.getBoundingClientRect().top; spread = 1; }; canvas.ontouchstart = function(event) { spread = 0; mouseX = event.targetTouches[0].clientX - canvas.getBoundingClientRect().left; mouseY = event.targetTouches[0].clientY - canvas.getBoundingClientRect().top; for (var i = points.length; i--; ) { points[i].x = mouseX; points[i].y = mouseY; } if (!event.target.href) { event.preventDefault(); } }; window.onresize = resize; resize(); mouseX = canvas.width / 2; mouseY = canvas.height / 2; update(); } on('DOMContentLoaded', init); |
Идея и доработка придумана, а основной код найден на codepen.io у пользователя Paul Neave
